Asus PRIME A620M-K DDR5 AMD AM5 Socket Motherboard

The ASUS PRIME A620M-K is a Micro-ATX motherboard designed for AMD's AM5 socket. It supports Ryzen 7000, 8000, and 9000 series processors and offers a balanced feature set suitable for mainstream users and budget-conscious builders seeking DDR5 support and PCIe 4.0 connectivity.​

Key Specifications

CPU & Chipset

• Socket: AM5

• Supported CPUs: AMD Ryzen 7000, 8000, and 9000 Series

• Chipset: AMD A620​

Memory

• Type: DDR5 (Non-ECC, Un-buffered)

• Slots: 2 x DIMM

• Max Capacity: 96GB

• Supported Speeds: Up to DDR5-7200 (OC)

• Features: Dual Channel Architecture, AMD EXPO™ support​

Graphics

• Integrated Graphics Support: Requires a CPU with an integrated GPU

• Video Outputs: 1 x HDMI 2.1 (4K@60Hz), 1 x VGA (D-Sub)​

Expansion Slots

• 1 x PCIe 4.0 x16: Supports x16 mode with Ryzen 7000/9000 series; x8/x4 with Ryzen 8000 series

• 1 x PCIe 3.0 x1​

Storage

• M.2 Slots: 1 x M.2 (Key M, 2242/2260/2280, PCIe 4.0 x4)

• SATA Ports: 4 x SATA 6Gb/s

• RAID Support: RAID 0, 1, 10 for both SATA and PCIe storage​

Audio & Networking

• Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC

• LAN: Realtek 1Gb Ethernet​

USB Ports

• Rear I/O:

  • 4 x USB 3.2 Gen 1 Type-A

  • 2 x USB 2.0 Type-A

• Front Panel Headers:

  • 1 x USB 3.2 Gen 1 header (supports 2 ports)

  • 2 x USB 2.0 headers (support 4 ports)​

Internal Connectors

• 1 x 24-pin Main Power connector

• 1 x 8-pin +12V Power connector

• 1 x 4-pin CPU Fan header

• 1 x 4-pin Chassis Fan header

• 2 x Addressable Gen 2 headers

• 1 x Aura RGB header

• 1 x Clear CMOS header

• 1 x COM Port header

• 1 x Front Panel Audio header (AAFP)

• 1 x S/PDIF Out header

• 1 x Speaker header

• 1 x 10-1 pin System Panel header​

Form Factor & Dimensions

• Form Factor: Micro-ATX

• Dimensions: 22.6 cm x 22.1 cm​

BIOS

• Type: 256 Mb Flash ROM, UEFI AMI BIOS​

Operating System Support

• Windows 10

• Windows 11​

Special Features

• ASUS 5X PROTECTION III (including DIGI+ VRM, LANGuard, Overvoltage Protection, SafeSlot Core, Stainless-Steel Back I/O)

• ASUS Q-Design (Q-DIMM, Q-LED Core, Q-Slot)

• ASUS Thermal Solution with Aluminum heatsink design

• Aura Sync RGB support

• Bundled Software: Armoury Crate, AI Suite 3, Norton 360 Deluxe (60 Days Free Trial), WinRAR

  Summary

  The ASUS PRIME A620M-K offers a solid foundation for building a modern AMD-based system with DDR5 memory and PCIe 4.0 support. Its Micro-ATX form factor makes it suitable for compact builds, and features like Aura Sync RGB and comprehensive connectivity options add value for users seeking both performance and aesthetics.​
